1. Brand new appearance design, fashionable and atmospheric, balancing aesthetics and functionality;
2. Stronger acceleration, climbing, and traction performance, faster lifting and lowering speeds, significantly improved work efficiency;
3. Intelligent instruments monitor the status of the forklift in real-time, ensuring safety and reliability; Soft connected intelligent gearbox for more comfortable operation;
4. Adoption of load sensing steering system and dual-pump combined flow hydraulic system reduces forklift energy consumption by 5%;
5. Forward CAE simulation analysis, 500h strengthening test of key components and the entire machine, with better reliability;
6. The hood is opened at a large angle, and the key maintenance parts adopt modular design, making maintenance convenient and efficient;
7. Equipped with domestic Yuchai power to meet Euro V emission, strong power and high cost performance.
Workplace: Widely used in factories, warehouses, stations, wharves, airports, ports, etc. for loading and unloading of packaged goods, and can also be used for loading and unloading of bulk cargoes and non-packaged cargoes after being equipped with other work attachments.
Model Designation | CP(C)D40/ CP(Q)(Y)D40 | CP(C)D45/ CP(Q)(Y)D45 | CP(C)D50/ CP(Q)(Y)D50 | CP(C)D55/ CP(Q)(Y)D55 | |
Load Capacity | kg | 4000 | 4500 | 5000 | 5500 |
Load Center | mm | 500 | 500(600) | ||
Wheel base | 2100 | 2100 | 2100 | 2100 | |
Overall height(overhead guard) | mm | 2350 | 2350 | 2350 | 2350 |
Overall length(without fork) | mm | 3185 | 3205 | 3255 | 3305 |
Overall width | mm | 1510 | 1510 | 1510 | 1510 |
Min.outside turning radius | mm | 2850 | 2880 | 2930 | 2970 |
