1. Standardly equipped with professional wide base off-road pattern tires, which is convenient for outdoor rough road conditions;
2. The radiator structure and cooling system space are optimized, which improves the heat dissipation performance and temperature control of the whole machine, and makes it more adaptable to harsh working conditions;
3. Two-wheel drive four-wheel drive convenient switching, high efficiency and energy saving;
4. Equipped with front 2 rear 1 gearbox, soft-connected wet drive axle, strong climbing ability, large ground clearance, and greatly improved off-road performance;
5. The hydraulic system is installed with load sensing system, greatly improved the lifting speed and operation efficiency;
6. With the lightweight design of the mast, widened frame and optimized design of the upper crossbeam, the strength of the lifting system is improved and the loading capacity is stronger;
7. Full-enclosed instrument panel, IP65 high protection grade LCD meter, high-end configuration, comfortable operation.
Model Designation | CPCD20 | CPCD25 | CPCD30 | CPCD35 | |
Load capacity | kg | 2000 | 2500 | 3000 | 3500 |
Load center | mm | 500 | 500 | 500 | 500 |
Min.outside turning radius | mm | 3400 | 3400 | 3400 | 3400 |
Other | 2WD / 4WD |
