1. Electronic power steering system.
2. Floating bodies with patent design. AC Driving system.
3. Automatic lifting limit. Load backrest is standard. Side-way battery.
4. Curve automatic deceleration more safe.
5. Stepless speed control system. Emergency reversing device. Emergency brake switch.
6. Options: FAAM 330/490Ah battery. Different length forksLithium battery.
| Model | CBD35-510 | CBD35-520 | CBD35-530 | |
| Rated capacity | kg | 3500 | 3500 | 3500 |
| Load center | mm | 1216 | 600/680/760 | 600/680/760 |
| Lift height | mm | 145 | 145 | 145 |
| Min.outside turning radius | mm | 2708 | 2190 | 2051 |
| Max.traveling speed (Loaded/Unloaded) | km/h | 11/14 | 11/14 | 4/4.5 |
| Controller | AC Controller | |||
